Magellan for Java


This package is a development package for Java to use Logitech Magellan (Space Mouse) on Java platforms. Please chceck the download site on to get the package and the samples.



To use the package, you have to install latest Java Communications API.
You can get the packages from Sun’s Java site.

Class Overview

Magellan Class

public class Magellan {
  public Magellan(int device);
  public void start();
  public void stop();
  public void getTranslation(int trans[3]);
  public void getRotation(int rot[3]);
  public void getButtons();

Magellan(int device)

This constructor creates an instance that is used to communicate with a Magellam device. Specify a number of the serial port into the device argument. You can use the platform independent defines Magellan.SERIAL1 or Magellan.SERIAL2.

void start()

This method starts a thread that updates the sensor records. To get the valid records by getTranslation(), getRotation() and getButton(), you have to call the methods after you starts the thread using this method.

void stop()

This method stops a thread that is started by start().

void getTranslation(int trans[3])

This method retrieves a current translation infomation.

void getRotation(int rot[3])

This method retrieves a current rotation infomation.

int getButtons()

This method retruns a current button infomation. Use the following constants are defined in the class to determine whether the buttons are currently pressd.

Magellan.BUTTON1 0x0001
Magellan.BUTTON2 0x0002
Magellan.BUTTON3 0x0004
Magellan.BUTTON4 0x0008
Magellan.BUTTON5 0x0010
Magellan.BUTTON6 0x0020
Magellan.BUTTON7 0x0040
Magellan.BUTTON8 0x0080
Magellan.BUTTONA 0x0100

For example, If you want to know whether the button1 is currently pressed ….

Magellan magellan = new Magellan( .... );
int button = magellan.getButtons();
if ((button & Magellan.BUTTON1) != 0)


Input Device Driver for Java3D

This is a simple input device driver for Java3D using the Magellan
driver, and you can walk in the world using Magellan. When the asterisk
are pressed, your viewpoint is reseted.



Revision Date Note
1.0 1999/05/20 The first release.


This package is provided “AS IS”. Licenser disclaims all warranties,
including but not limited to, all express or implied warranties of
merchant ability and fitness for a particular purpose. Everyone can use
the package for commerce or personal purposes free.
